PEREGRINA
Our new vessels are specifically designed for offshore platform supply, delivering comprehensive and high-efficiency logistical solutions for oilfield operations and maintenance.
General Specifications
| Class | LR 100 A1 Offshore Support Vessel, FireFighting Ship 1(2400m3/h) with Water Spray, HNLS, Oil Recovery, RD (Tank Nos. 1-4, 2.4), WDL (10t/m2), IWS LMC, UMS, DP (AA) |
| Design | MMC-887 CD |
| Flag | México |
| IMO Number | 9743069 |
| HULL NUMBER | MW619 CD-3 |
| Year Built | 2019 |
| Builder | FUJIAN MAWE SHIPBUILDING LTD. |
Main Particulars
| Lenght Overall | 286.3 ft. / 87.3 m |
| Length BP | 272.3 ft. / 83.0 m |
| Beam | 61.7 ft. / 18.8 m |
| Depth Moulded | 24.3 ft. / 7.4 m |
| Max Summer Draft | 19.8 ft. / 6.05 m |
| Gross Tonnage | 3924 T |
| Net Tonnage | 1726 T |
| Dead Weight | 5100 T |
Capacities
| Fuel Oil | 251,244.7 USG / 951.07 m³ |
| Fresh Water | 233,264 USG / 883 m³ |
| Potable Water | 18,492 USG / 70 m³ |
| Drill Water | 466,792 USG / 1767 m³ |
| Dry Bulk | 14,974 ft³ / 424 m³ |
| Liquid Mud | 12,813 Bbls / 2037 m³ |
| Methanol | 2,107 Bbls / 335 m³ |
| Base Oil | 58,269.2 USG / 220.58 m³ |
ACCOMODATIONS
| Cabins/Berths (Total) | 27 Cabins / 52 persons |
| Single Berth Cabins | 6 (with attached heads) |
| Double Berth Cabins | 19 (with attached heads) |
| Four Berth Cabins | 2 (with attached heads) |
| Hospital | 1 |
| Ship's Office | 1 |
Cargo Deck & Equipment
| Deck Area | 10,764 ft² / 1000 m² |
| Deck Cargo | 2,362 LT / 2400 MT |
| Deck Strength | 1048 lb/ft² / 5 MT/m² |
| Deck Crane | 2 x NGSU HAITAI - 3T @ 10 m |
| Deck Tuggers | 2 x Jiangsu - 10T @ 15m/min |
| Capstans | 2 x Jiangsu - 8T @ 20m/min |
Discharge Rates
| Type | USG/Min | @ Ft Head | M³/hr | @ M Head |
|---|---|---|---|---|
| Fuel Oil | 660USG/Min | 302@Ft Head | 150M³/hr | 92 @M Head |
| Ballast/Drill Water | 660USG/Min | 302@Ft Head | 150M³/hr | 92@M Head |
| Fresh Water | 660USG/Min | 302@Ft Head | 150M³/hr | 92@M Head |
| Liquid Mud | 330USG/Min | 279@Ft Head | 75M³/hr | 85@M Head |
| Methanol | 330USG/Min | 376@Ft Head | 75M³/hr | 115@M Head |
| Dry Bulk | 706 ft³/minUSG/Min | - | 20 m³/minM³/hr | - |
Safety Equipment
| Rescue Boat | 1 x SOLAS MOB for 15 persons |
| Launch & Recovery Davit | ZHENJIANG WEST MARINE LRH35 |
| Life Rafts | 4 x 20 man each side |
| Life Buoys | 10 |
| Life Jackets | 59 |
Vessel Performance
| Max Speed | 14.3 knots |
| Service Speed | 10 knots |
| DP-2 Fuel Consumption | 3726 USG/day / 12 MT/day |
| Service Speed Consumption | 4619 USG/day / 15 MT/day |
| Maximum Speed Consumption | 8052 USG/day / 26 MT/day |
Machinery
| Main Generator Engines | 4 x Caterpillar 3512 (9120 HP; 6800 kW) |
| Main Generators | 4 x ABB at 1888 kVA each |
| Main Drives | 2 x 2000 kW Rolls Royce Azimuth Thrusters |
| Emergency Generator | 1 x Caterpillar C-18 (350 kW) |
| Tunnel Bow Thruster | 1 x 910 kW Rolls Royce |
| Retractable Bow Thruster | 1 x 800 kW Rolls Royce Azimuth |
Dynamic Positioning System
| DP Class 2 | Kongsberg K-Pos-22 |
| Independent Joystick | Kongsberg C-Joy |
| Reference System | CyScan Multi-Target Laser MK-4 |
| Gyroscopes | 3 x Anschutz DigitalGyro STD 22 |
| MRU | 3 x Nautica Dynamics PIRO 25d |
| DGPS | 2 x Kongsberg DPS 112/110 |
| HIPAP | Sea chest ready for HiPAP 500 |
Fire Fighting Equipment
| FIFI System | Class - 1 c/w water spray system |
| Monitors | 2 x Jason @ 1200 m³/hr |
| Fire Pumps | 2 x Jason BBB1921 @ 1300 m³/hr |
