LA BAMBA

Multi-purpose vessel in support of offshore construction and maintenance activities. Activities carried out in the coast of Tabasco and Campeche, Mexico.

KINDOffshore Support Vessel
CLASSIFICATIONABS A1 (E) AMS. Offshore Support Vessel, Fire Fighting Vessel Class 1, ⁺ACCU, ⁺DPS- 2, HELIDK, Unrestricted Service, RW.
SHIP HULL NUMBERDN85M-2
YEAR OF CONSTRUCTION2014
SHIPYARDFujian Southeast Shipyard
SETTING KEEL2013-06-27
FLAGMéxico
PORT OF REGISTRATIONIsla Del Carmen
IMO NUMBER9680762
AIR DRAFT39.6 mts
GROSS TONNAGE4,760 tons
NET TONNAGE1,428 tons
DEAD WEIGHT3109 tons
DISPLACEMENT7,233 tons
BALLAST WATER280 m3
SLUDGE TANK410 m3
FREE AREA ON DECK865 m2
LOADING ON DECK (7.5 ton/m2)800 tons
MACHINERY2X NIIGATA 6L28AHX
MAIN CRANEMACGREGOR 100 tons
AUXILIARY CRANEGOOD CRANE 30 tons
ROOM CAPABILITY250 PEOPLE
FI-FIFIFI 1 FFS 1200LB 1200m3/hr 120m from monitor
WATER TREATMENTX2 PETER TABOADA 30 m3/dia
DISTINCTIVE CALL SIGNXCAS5
MMSI345-070-056
ID INMARSAT C-SSAS434501040
ID INMARSAT C-LRIT434501042
OFFICIAL NUMBER04013745324
TOTAL LENGTH85 mts
LENGTH LINE IN WATER81.128 mts
LENGTH BETWEEN PERPENDICULAES77.750 mts
BEAM22 mts
MOULDED DEPTH8 mts
DRAFT BERTHS6.3 mts
DRY WEIGHT4124 tons
MAXIMUM SPEED12.5 Kts
DIESEL CAPACITY1,150 m3
FRESH WATER740 m3
DRILL WATER1,750 m3
Heeling/Drill Water Tank440 m3
SILOS (4x2,000 Ft3)226 m3
TOTAL POWER (KW)4412 KW
POSITIONING OF 4 POINTS4 ANCHORS
MAIN GENERATORS3 x 800kW Caterpillar each
ATERNATING GENERATORSTwo tail generators of 1,500KW each
